Borche Screw Barrel
ROOTIER supplies replacement and custom screw barrels for Borche injection molding machines. Our solutions cover different Borche machine models and injection units, with screw diameters from Ø25 to Ø150 mm. Screw and barrel configurations can be manufactured according to the machine specification, screw diameter, L/D ratio and processed resin. Refer to the product data below to find the available Borche screw barrel sizes.
Product data
| Product Name | Borche Series |
|---|---|
| Tonnage | 10-2000T |
| Brand | ROOTIER |
| Screw Diameter | 16-200mm |
| Material | Bimetallic, Hardened |
| Application | PP, PE, PS, PVC, PA, PBT, PEEK, PVC, LCP, POM, PC.. |
Specification
Borche Injection Unit Screw Barrel Size
| Model | Injection Unit | Screw Size |
|---|---|---|
| BS60-III | 153/60 | Ø25, Ø28, Ø30, Ø35, Ø40 |
| BS80-III | 252/80 | Ø35, Ø40, Ø45 |
| BS120-III | 388/120 | Ø40, Ø45, Ø50 |
| BS150-III | 634/150 | Ø45, Ø50, Ø60 |
| BS200-III | 849/200 | Ø50, Ø60, Ø70 |
| BS260-III | 1367/260 | Ø60, Ø70, Ø80 |
| BS320-III | 2239/320 | Ø70, Ø80, Ø90 |
| BS400-III | 3266/400 | Ø75, Ø85, Ø95 |
| BS500-III | 3925/500 | Ø80, Ø85, Ø95 |
| BS560-III | 4156/560 | Ø80, Ø90, Ø100 |
| BS650-III | 4435/650 | Ø90, Ø100, Ø105 |
| BS800-III | 5700/800 | Ø100, Ø105, Ø115 |
| BS1000-III | 7550/1000 | Ø105, Ø115, Ø130 |
| BS1300-III | 11500/1300 | Ø105, Ø115, Ø130, Ø140, Ø150 |
Frequently Asked Questions
Yes. ROOTIER manufactures replacement screws, barrels, screw tips, non-return valves and nozzles engineered to fit Borche injection molding machines. Standard sizes are held in stock for common models, and custom components are produced to drawing or sample.
Send your Borche machine model, injection unit, screw diameter and L/D ratio together with the resin you process. ROOTIER will recommend the matching screw geometry, material and surface treatment for your application.
ROOTIER offers nitrided 38CrMoAlA, bimetallic-lined and fully hardened screws and barrels, with chrome plating, PVD or HVOF coatings selected for the resin, filler content and wear conditions of your Borche machine.
ROOTIER supplies screws and barrels for Borche BS60-III through BS1300-III machines, with screw diameters from Ø25 to Ø150 mm.
Yes. ROOTIER offers bimetallic barrels and HVOF / tungsten-carbide wear-clad screws for Borche injection units processing glass-fiber or mineral-filled compounds.
